Optrex T-51750GD065J-FW-ADN
| Manufacturer: | Optrex |
|---|---|
| Model: | T-51750GD065J-FW-ADN |
| Price: | $196.00 |
| Availability: | Check Availability |
|
Optrex T-51750GD065J-FW-ADN 6.5" anti-glare LCD screen with a 640x480 maximum resolution and 2 CCFL backlights. Accepts 6-bit display directions over a 31-pin input interface. This panel is frequently found in many applications, including Triton model RT2000 ATM machine and Philips Avalon FM20, FM30 medical monitors. The T-51750GD065J-FW-ADN is eligible for our repair service: T-51750AB-REP. |
|
| This item comes with a 180 day warranty covering units which are defective upon arrival. Defective products can be returned within 180 days of the sale for replacement or refund. More details about our warranty can be found in our Terms & Conditions. | |
| Some production models use various internal part configurations. Always ensure that the part used in your machine is compatible with the model listed here before purchasing. | |
| Additional Information | |
|---|---|
| Common Applications | Triton RT2000 |
| Philips Avalon FM20 | |
| Philips Avalon FM30 | |
| Application Part Numbers | 01160-00025 |
| Short Description | 6.5" LCD |
| Interface | |
| Display Data | 6-bit |
| Input Connector Pins | 31 |
| Display | |
| Resolution | 640x480 |
| Lamps No. | 2 |
| Size | 6.5" |
| Lamp Type | CCFL |
| Surface Treatment | Anti-Glare |
| Brightness | 400cd/m^2 |
| Contrast Ratio | 300:1 |
| Horizontal Viewing Angle | 55 |
| Viewing Angle (Up) | 30 |
| Viewing Angle (Down) | 60 |
| Power | |
| Input Voltage | 3.3-5.0VDC |
